HB 1575 Bi-Fold Flush Pull



The HB1575 is a continuation of the flush pull story. It’s 510 mm x 70m m size gives you the option of a flush finish on pivot or bifold doors on a grand scale. The increased finger grip provides efficient leverage for oversized doors.

Available in a wide range of sizes and finishes, the Halliday + Baillie Flush Pulls are beautifully designed with concealed fixing (without exposed screw fasteners) for a pared back and sophisticated contemporary look.

Sold individually. For double-sided use, install one pull on each side of the door. If installing on a pocket door, pair with an Edge Pull to pull the door from its recessed position. Combine with HB 680 Push Button Edge Pull for a matching set.

Made in New Zealand.



Specifications



Suitable for wood or aluminium doors

L 510 mm (20") x W 70 mm (2.75") x D 17 mm (.67") Internal Grip Depth: 14 mm (.55")

• Minimum door thickness 36 mm (1.4") if used back to back, 45 mm (1.8") if used with end pulls.
• This flush pull is handed. Specify LH or RH
• Glue, epoxy, silicone products etc are not required or recommended for installation.

Material(s)



Solid Brass

Finishes:

• SC: Satin Chrome
• PC: Polished Chrome
• BN: Brushed Nickel
• PB: Polished Brass

• WHT: Powder Coat White
• EBA: Powder Coat Electro ™ Black Ace
• EMB: Powder Coat Electro ™ Medium Bronze
• EDB: Powder Coat Electro ™ Dark Bronze

Complete Finishes List and here
